Coeur Bolt Stainless Hanger – 10 mm

Coeur Bolt Stainless Hanger

Vendor: Petzl
SKU: P36BS 10
Why we like it
Stainless steel anchor composed of a COEUR STAINLESS hanger, a bolt and a nut, designed for typical exterior uses. It is available in 10 and 12 mm diameters.

$175.95

Estimated Time Until Ship: 1 Business Days


Add to Wishlist


About: Petzl - Coeur Bolt Stainless Hanger

Complete and durable assembly:
  • Comprised of a COEUR STAINLESS hanger, nut and bolt
  • 316L stainless steel offers excellent resistance to corrosion in typical exterior environments
  • Hanger anti-rotation system: textured back keeps the hanger from turning when the anchor is being installed or when it is heavily laterally loaded during use
Easy clipping:
  • The wide, ergonomic connection hole facilitates carabiner clipping
  • The width of the hole allows installation of two carabiners at the same time

Prevents wear of carabiners: the thickness of the hanger and the rounded edges of the connection hole limit wear of carabiners

Available in two bolt sizes (10 or 12 mm)

Resources

User Instructions



Specifications

  • Material(s): 316L stainless steel

Certifications

  • EN 959

Reference Table

References P36BS 10 P36BS 12
Diameter 10 mm 12 mm
Weight 110 g 135 g
Length 7 cm 8.5 cm
Drilling depth 7 cm 8.5 cm
Drilling diameter 10 mm 12 mm
Resistance to cutting on concrete 50 MPa 25 kN 25 kN
Pull-out strength in concrete 50 MPa 25 kN 25 kN
Guarantee 3 years 3 years
Packing 1 1
