Aluminum Belay Spool – 2

Aluminum Belay Spool

Vendor: Robertson Mountaineering
SKU: 3015
Why we like it
The Robertson Belay spool is a platform highly recommended for commercial applications.

$88.59

Estimated Time Until Ship: 5 Business Days


Add to Wishlist


About: Robertson Mountaineering - Aluminum Belay Spool

  • Available in double pin.
  • Can be used as a self-belay or with a belayer.
  • Single pin can accept up to a ⅝-inch (15.9 mm) rope
  • Double pin can accept up to a ½-inch (12.7mm) rope
  • Wall thickness of.180 around clip-in hole and .090 around back-up bolt.
  • Outstanding durability and structural design for 25 years.
  • Side plates are .105-inch thick, made of 304 stainless steel for superior strength.
  • Aluminum cylinder allows the spool to cool more rapidly than a stainless steel cylinder spool.
  • Ability to accept two steel carabiners in the becket.
  • The Robertson Belay spool is a platform highly recommended for commercial applications.

Resources

User Instructions - Single Pin
User Instructions - Double Pin



Specifications

  • Material(s): Aluminum
  • Available in Single and Double Pin

Reference Table

References 3005 3015
Length 3 inches(76.2 mm) 3 inches (76.2 mm)
Height 5 7/8 inches(149.2 mm) 5 7/8 inches (149.2 mm)
Width 2 5/8 inches (67 mm) 2 5/8 inches (67 mm)
Recommended Rope 5/8 inches 1/2 inches
